Overview

Inconel 82 (AWS ERNiCr-3) is a nickel-chromium welding wire used for GTAW and GMAW welding of Inconel 600, 601, and 690, as well as dissimilar welds between nickel alloys and steels. Excellent oxidation resistance and ductility.

Welding Parameters

Parameter	GTAW	GMAW
Shielding Gas	Argon (99.995%)	Ar + 2% He or Ar + 2% CO2
Gas Flow Rate	8-15 L/min	15-25 L/min
Wire Diameter	1.6-3.2 mm	0.8-1.6 mm
Current Type	DCEN	DCEP
Welding Position	All positions	Flat / Horizontal

Applications

Inconel 82 welding wire is used in a wide range of demanding applications:

• Dissimilar Welds: Joining nickel alloys to carbon and stainless steels.
• Inconel 600/601: Welding of Inconel 600 and 601 components.
• Nuclear: Welding of nuclear reactor components.
• Petrochemical: Weld overlay on steels for corrosion protection.
• Heat Treatment: Welding of furnace components and fixtures.

Available Product Forms

Hangbo Alloy Group supplies Inconel 82 welding wire in the following forms:

• TIG Wire: Straight lengths 1000 mm, diameters 1.6 mm, 2.0 mm, 2.4 mm, 3.2 mm.
• MIG Wire: Precision-wound spools (D200, D300), diameters 0.8 mm, 1.0 mm, 1.2 mm, 1.6 mm.
• SAW Wire: Coils for submerged arc welding, diameters 2.4 mm, 3.2 mm, 4.0 mm.

Related Standards

Standard	Description
AWS A5.14	ERNiCr-3
ISO 18274	S Ni 6082
EN ISO 18274	S Ni 6082
DIN 1736	SG-NiCr20Mn3Nb

Chemical Composition of ERNiCr-3 Welding Wire (wt%)

Element	Content (%)
Nickel (Ni)	67.0 min
Chromium (Cr)	18.0 – 22.0
Manganese (Mn)	2.5 – 3.5
Niobium + Tantalum (Nb+Ta)	2.0 – 3.0
Iron (Fe)	3.0 max
Titanium (Ti)	0.75 max

Mechanical Properties of Deposited Metal

Property	Typical Value
Tensile Strength	620 MPa (90 ksi) min
Yield Strength (0.2%)	350 MPa (51 ksi) min
Elongation	30% min
Service Temperature	up to 900°C (1650°F)

Values above are typical for as-welded Inconel 82 (ERNiCr-3) deposited metal under AWS A5.14 classification requirements. Actual results vary with welding process, heat input and shielding gas.

Why Choose Inconel 82 Welding Wire

• The industry-standard filler for dissimilar welding between nickel alloys and carbon or stainless steels.
• Manganese and niobium provide strong resistance to hot cracking and weld metal microfissuring.
• Retains oxidation resistance and creep strength at elevated temperature.
• Extensively qualified for nuclear, petrochemical and power generation service.

Welding Best Practices

Follow these practical guidelines to obtain sound, corrosion-resistant welds with this filler metal:

• Buttering the steel face is recommended when dilution is expected to exceed about 30%.
• Keep interpass temperature below 175°C (350°F); preheat only per the steel base-metal procedure.
• Use high-purity argon shielding with a gas lens; avoid excessive arc length.
• Remove oxides between passes with a dedicated stainless brush used only for nickel alloys.

Frequently Asked Questions

Contact Us for Inconel 82

Hangbo Alloy Group supplies Inconel 82 (ERNiCr-3) welding wire with full material certifications. We ensure consistent wire quality with precise diameter control, clean surface finish, and uniform feeding performance.

For quotations, material certifications, or technical consultation, contact our sales team or call +86 166 2109 2936.
