Overview

Inconel 92 (AWS ERNiCrFe-6) is a nickel-chromium-iron welding wire for welding Inconel 600, 601, and similar alloys. Provides good strength and ductility at elevated temperatures with excellent resistance to oxidation.

Welding Parameters

Parameter	GTAW	GMAW
Shielding Gas	Argon (99.995%)	Ar + 2% He or Ar + 2% CO2
Gas Flow Rate	8-15 L/min	15-25 L/min
Wire Diameter	1.6-3.2 mm	0.8-1.6 mm
Current Type	DCEN	DCEP
Welding Position	All positions	Flat / Horizontal

Applications

Inconel 92 welding wire is used in a wide range of demanding applications:

• Inconel 600/601: Welding of furnace and heat treatment components.
• Dissimilar Welds: Joining nickel alloys to stainless steels.
• Petrochemical: Welding of high-temperature process equipment.
• Power Generation: Welding of boiler and superheater components.
• Chemical Processing: Welding of corrosion-resistant process equipment.

Available Product Forms

Hangbo Alloy Group supplies Inconel 92 welding wire in the following forms:

• TIG Wire: Straight lengths 1000 mm, diameters 1.6 mm, 2.0 mm, 2.4 mm, 3.2 mm.
• MIG Wire: Precision-wound spools (D200, D300), diameters 0.8 mm, 1.0 mm, 1.2 mm, 1.6 mm.
• SAW Wire: Coils for submerged arc welding, diameters 2.4 mm, 3.2 mm, 4.0 mm.

Related Standards

Standard	Description
AWS A5.14	ERNiCrFe-6
ISO 18274	S Ni 6092
EN ISO 18274	S Ni 6092
DIN 1736	SG-NiCr15FeMn

Chemical Composition of ERNiCrFe-6 Welding Wire (wt%)

Element	Content (%)
Nickel (Ni)	67.0 min
Chromium (Cr)	14.0 – 17.0
Iron (Fe)	8.0 – 12.0
Manganese (Mn)	2.0 – 3.5
Niobium + Tantalum (Nb+Ta)	1.5 – 3.0
Titanium (Ti)	1.5 max

Mechanical Properties of Deposited Metal

Property	Typical Value
Tensile Strength	620 MPa (90 ksi) min
Yield Strength (0.2%)	340 MPa (49 ksi) min
Elongation	35% min
Service Temperature	up to 900°C (1650°F)

Values above are typical for as-welded Inconel 92 (ERNiCrFe-6) deposited metal under AWS A5.14 classification requirements. Actual results vary with welding process, heat input and shielding gas.

Why Choose Inconel 92 Welding Wire

• Manganese and niobium work together to give excellent resistance to hot cracking and microfissuring.
• Purpose-designed for dissimilar welding of nickel alloys to carbon and low-alloy steels.
• Tolerates high iron dilution from the steel side without forming brittle phases.
• Long-standing nuclear-qualified filler for reactor pressure vessel dissimilar metal welds.

Welding Best Practices

Follow these practical guidelines to obtain sound, corrosion-resistant welds with this filler metal:

• Apply a buttering layer on the steel side when dilution exceeds roughly 30%.
• Keep interpass temperature below 175°C (350°F); preheat carbon steel per its own procedure.
• Use DCEN polarity for GTAW with high-purity argon shielding.
• Peen or use low-restraint sequencing on highly restrained joints to relieve shrinkage stress.

Frequently Asked Questions
